Name: TLWR9600
Brand: Vishay Semiconductor Opto Division
SKU: TLWR9600
Availability: InStock

new-10%

TLWR9600

Manufacturer part number:TLWR9600

Manufacturer:Vishay Semiconductor Opto Division

Description:TLWR9600 datasheet pdf and LED Indication - Discrete product details from Vishay Semiconductor Opto Division stock available on our website

Case Package:SOT-23

Datasheet:TLWR9600 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	4-DIP (0.200, 5.08mm)
Number of Pins	4
Packaging	Tube
Series	TELUX™
Published	2008
Size / Dimension	7.62mm Lx7.62mm W
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Max Operating Temperature	110°C
Min Operating Temperature	-40°C
Color	Red
Voltage - Rated DC	2.2V
Depth	7.62mm
Base Part Number	TLW9600
Number of Elements	1
Configuration	Standard
Power Dissipation	187mW
Voltage - Forward (Vf) (Typ)	2.2V
Viewing Angle	60°
Forward Current	70mA
Current - Test	70mA
Lens Style	Round with Domed Top
Forward Voltage	2.2V
Luminous Intensity	2.56 cd
Illumination Color	Red
Lens Transparency	Clear
Wavelength - Peak	624nm
Lens Color	Colorless
Luminous Flux	3.2 lm
Reverse Voltage	20V
Wavelength - Dominant	615nm
Number of LEDs	1
Height	6.4mm
Length	7.62mm
Width	7.62mm
Height (Max)	6.40mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

About TLWR9600

The TLWR9600 from Vishay Semiconductor Opto Division is a high-performance microcontroller designed for a wide range of embedded applications. This component features TLWR9600 datasheet pdf and LED Indication - Discrete product details from Vishay Semiconductor Opto Division stock available on our website.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the TLWR9600, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
