MM74HCT74SJX Overview
The flip flop is packaged in a case of 14-SOIC (0.209, 5.30mm Width). It is contained within the Tape & Reel (TR)package. This output is configured with Differential. Positive Edgeis the trigger it is configured with. Surface Mountmounts this electrical part. The JK flip flop operates at a voltage of 4.5V~5.5V. In the operating environment, the temperature is -40°C~85°C TA. This electronic flip flop is of type D-Type. This type of FPGA is a part of the 74HCT series. Its output frequency should not exceed 27MHz. The element count is 2 . This process consumes 2μA quiescents. In 14terminations, a transmission line is terminated with a JK flip flop that matches its characteristic impedance. The object belongs to the 74HCT74 family. Power is provided by a 5V supply. This JK flip flop has a 5pFfarad input capacitance. A device of this type belongs to the family of HCT. Vsup reaches 5.5V, the maximal supply voltage. Normally, the supply voltage (Vsup) should be kept above 4.5V.
MM74HCT74SJX Features
Tape & Reel (TR) package
74HCT series
MM74HCT74SJX Applications
There are a lot of ON Semiconductor MM74HCT74SJX Flip Flops applications.
- ESD protection
- Computers
- Consumer
- Clock pulse
- Frequency Dividers
- Cold spare funcion
- Balanced Propagation Delays
- Pattern generators
- Matched Rise and Fall
- Patented noise
