Name: RSJ300N10TL
Brand: ROHM Semiconductor
SKU: RSJ300N10TL
Availability: InStock

new-10%

RSJ300N10TL

Manufacturer part number:RSJ300N10TL

Manufacturer:ROHM Semiconductor

Description:MOSFET N-CH 100V 30A LPTS

Case Package:SOT-23

Datasheet:RSJ300N10TL Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins	83
Transistor Element Material	SILICON
Operating Temperature	150°C TJ
Packaging	Tape & Reel (TR)
Published	2011
Part Status	Not For New Designs
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Technology	MOSFET (Metal Oxide)
Terminal Form	GULL WING
Pin Count	3
JESD-30 Code	R-PSSO-G2
Number of Elements	1
Number of Channels	1
Power Dissipation-Max	50W Tc
Element Configuration	Single
Operating Mode	ENHANCEMENT MODE
Turn On Delay Time	20 ns
FET Type	N-Channel
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	52m Ω @ 15A, 10V
Vgs(th) (Max) @ Id	2.5V @ 1mA
Input Capacitance (Ciss) (Max) @ Vds	2200pF @ 25V
Current - Continuous Drain (Id) @ 25°C	30A Ta
Gate Charge (Qg) (Max) @ Vgs	50nC @ 10V
Rise Time	65ns
Drain to Source Voltage (Vdss)	100V
Drive Voltage (Max Rds On,Min Rds On)	4V 10V
Vgs (Max)	±20V
Fall Time (Typ)	180 ns
Turn-Off Delay Time	130 ns
Continuous Drain Current (ID)	30A
Gate to Source Voltage (Vgs)	20V
Drain-source On Resistance-Max	0.059Ohm
Pulsed Drain Current-Max (IDM)	60A
Height	4.5mm
Length	10.1mm
Width	9mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

About RSJ300N10TL

The RSJ300N10TL from ROHM Semiconductor is a high-performance microcontroller designed for a wide range of embedded applications. This component features MOSFET N-CH 100V 30A LPTS.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the RSJ300N10TL, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
