Name: 1868830
Brand: Phoenix Contact
SKU: 1868830
Price: 17.63000 USD
Availability: InStock

new

1868830

Manufacturer part number:1868830

Manufacturer:Phoenix Contact

Description:0.200 5.08mm Green Bulk Polyamide (PA), Nylon Through Hole Horizontal with Board Screw - Rising Cage Clamp 4 Levels 14-30 AWG COMBICON MK4DS

Case Package:SOT-23

Datasheet:1868830 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Material	Tin
Mount	Through Hole
Mounting Type	Through Hole
Number of Pins	12
Material	Polyamide
Housing Material	Polyamide (PA), Nylon
Weight	31.000005g
Packaging	Bulk
Series	COMBICON MK4DS
Published	2010
Feature	Interlocking (Side)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Screw
Number of Positions	3
Color	Green
Number of Rows	1
Gender	Male
Voltage - Rated	400V
Pitch	0.200 5.08mm
Orientation	Straight
Depth	48mm
Current Rating	15A
Wire Gauge	14-30 AWG
Voltage	300V
Number of Levels	4
Current	10A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	14 AWG
Number of Decks	1
Terminal and Terminal Block Type	BARRIER STRIP TERMINAL BLOCK
Torque - Screw	0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways	3
Safety Approval	UL
Mating Orientation	Horizontal with Board
Wire Termination	Screw - Rising Cage Clamp
Screw Thread	M3
Height	42.9mm
Length	15.24mm
Width	42.9mm
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1868830 Product Details

1868830 Overview

The packaging contains Screw.There is a Through Hole mounting type for the device.This product is packaged in a case marked Bulk.Product number COMBICON MK4DS belongs to the COMBICON MK4DS Series.A 12 pin is provided on the device.In many ways, it is more powerful due to its Interlocking (Side) feature.There is a Through Hole mount on the part.
