1770937

  • 1770937 - 0.098 2.50mm Black Tape & Reel (TR) Liquid Crystal Polymer (LCP) Through Hole Horizontal with Board Screwless - Spring Cage, Tension Clamp 1 Levels 20-26 AWG COMBICON PTSM
  • 1770937 - 0.098 2.50mm Black Tape & Reel (TR) Liquid Crystal Polymer (LCP) Through Hole Horizontal with Board Screwless - Spring Cage, Tension Clamp 1 Levels 20-26 AWG COMBICON PTSM

1770937

1770937

Phoenix Contact

0.098 2.50mm Black Tape & Reel (TR) Liquid Crystal Polymer (LCP) Through Hole Horizontal with Board Screwless - Spring Cage, Tension Clamp 1 Levels 20-26 AWG COMBICON PTSM

SOT-23

1770937 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 13 Weeks
Contact PlatingTin
Mount Through Hole
Mounting Type Through Hole
Housing Material Liquid Crystal Polymer (LCP)
PackagingTape & Reel (TR)
Series COMBICON PTSM
Published 2010
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
ECCN Code EAR99
Number of Positions 7
Color Black
Voltage - Rated 200V
HTS Code8536.69.40.40
Pitch 0.098 2.50mm
Orientation Horizontal
Current Rating6A
Wire Gauge20-26 AWG
Voltage 150V
Number of Levels 1
Current 5A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 20 AWG
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Mating Orientation Horizontal with Board
Wire TerminationScrewless - Spring Cage, Tension Clamp
Length 10mm
RoHS StatusRoHS Compliant
Flammability Rating UL94 V-0
In-Stock:5748 items

Pricing & Ordering

QuantityUnit PriceExt. Price
530$1.19700$634.41

1770937 Product Details

1770937 Overview


It's mounted Through Hole.We use a Tape & Reel (TR) case to package the product.It's from the COMBICON PTSM Series.It's mounted by Through Hole.

1770937 Features


COMBICON PTSM series


1770937 Applications


There are a lot of Phoenix Contact
1770937 Terminal Blocks applications.


  • Transportation
  • Embedded systems
  • Datacom
  • Communication
  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
